EAGLE LIGHT CP0603CD-7 — IP65 6-Channel TRUE1 DMX512 Dimming Distributor
The EAGLE LIGHT CP0603CD-7 distributes three-phase industrial input power across six 16 A TRUE1 socket outputs while offering DMX512 dimming for high-voltage LED and halogen lamps. The catalog specifies 90–240 V and 32 A per phase, a maximum of 16 A per output channel and an IP65 aluminum-profile waterproof chassis.
Key Features
- Six TRUE1 outputs: Six 16 A TRUE1 socket channels are identified.
- DMX512 dimming: The manufacturer specifically documents dimming of high-voltage LED and halogen lighting loads by DMX512.
- Three-phase input distribution: A three-phase five-wire industrial plug supplies the power outputs.
- IP65-rated enclosure: An aluminum-profile waterproof housing with IP65 protection is specified.
Professional Installation Applications
For controlled stage power layouts using TRUE1 connections and DMX512 dimming of compatible AC lighting equipment. Verify the required electrical protection and load behavior prior to wiring and operation.
Verified Technical Specifications
| Brand | EAGLE LIGHT |
|---|---|
| Manufacturer model | CP0603CD-7 |
| Product family | Distributed Power Distributor Series |
| Power input | Three-phase, five-wire industrial plug |
| Input voltage | 90–240 V per phase |
| Input current | 32 A per phase |
| Power outputs | 6 TRUE1 sockets, 16 A each |
| Lighting control | DMX512 dimming |
| Catalog-listed lighting types | High-voltage LED and halogen lamps |
| Maximum channel current | 16 A |
| Enclosure | Aluminum-profile waterproof chassis |
| Protection rating | IP65 |
Selection & Safety Notes
Confirm connector compatibility, electrical supply requirements, suitable protective devices and output loads before installation. Specifications not provided for this exact model are not estimated.
Source: supplied EAGLE LIGHT manufacturer catalog, PDF page 24.
