REDJET Professional Stage Lighting · STROBE 1212LS

Precision. Motion. Impact.

REDJET STROBE 1212LS is a 400 W professional motorized RGB pixel strobe combining high-speed white strobe output, RGB pixel effects, motorized tilt and advanced segment control in one fixture.

400 W · 96 RGB + 20 white segments · 1–30 Hz · DMX512 / RDM

Product Overview

Built for concerts, touring, rental, clubs, live venues and TV or broadcast productions, STROBE 1212LS combines 864 × 0.3 W RGB LEDs with 180 × 3 W white LEDs. Its 96 RGB segments and 20 independent white strobe zones support integrated effects as well as detailed pixel-mapped programming.

Motorized tilt, built-in effects and four DMX channel modes provide flexible control for both straightforward show setups and more complex lighting sequences.

Key Features

400 W motorized RGB pixel strobe.
864 × 0.3 W RGB LEDs and 180 × 3 W white LEDs.
96 independent RGB segments and 20 white strobe zones.
Motorized tilt with fine adjustment and speed control.
DMX512, RDM, Auto, Sound and Master/Slave modes.
32-bit linear dimming from 0–100%.
1–30 Hz strobe frequency.
6, 20, 41 and 312-channel DMX personalities.

Official Product Video

See the STROBE 1212LS in operation, including its RGB pixel effects, white strobe output and motorized movement.

Watch the official product video on YouTube

Technical Specifications

Lighting & Performance

Fixture Type	Motorized RGB Pixel Strobe
Power Consumption	400 W
RGB Light Source	864 × 0.3 W RGB LEDs
White Light Source	180 × 3 W white LEDs
Independent Segments	96 RGB + 20 white strobe zones
Strobe Frequency	1–30 Hz
Dimming	32-bit linear, 0–100%

DMX & Movement

DMX Personalities	6 / 20 / 41 / 312 CH
Control Modes	DMX512, RDM, Auto, Sound, Master/Slave
Motorized Tilt	Tilt, fine adjustment and speed control

Electrical & Construction

Power Supply	AC 100–240 V, 50/60 Hz
Operating Temperature	-30 °C to +50 °C
Housing / Protection	Black metal / IP20
Fixture Dimensions	Approx. 516 × 215 × 229 mm

DMX Modes & Channel Maps

The 20 CH mode is recommended for standard operation. Open any channel mode below to see its documented DMX assignments.

6 CH — Basic Control

Compact control of tilt, reset, white output and direct RGB intensity.

CH	Function / Operation	DMX Range
1	Tilt — motorized tilt	0–255
2	Reset — no function / full reset	0–126 / 127–128
3	White Strobe Dimmer — 0–100%	0–255
4	Red — intensity	0–255
5	Green — intensity	0–255
6	Blue — intensity	0–255

20 CH — Recommended

General-purpose control with movement, RGB intensity, white strobe and built-in effects.

CH	Function / Operation	DMX Range
1	Tilt — vertical movement	0–255
2	Tilt Fine — 16-bit adjustment	0–255
3	Tilt Speed — fast to slow	0–255
4	Reset — no function / full reset	0–126 / 127–128
5	Master Dimmer — 0–100% intensity	0–255
6	RGB Strobe / Flicker — constant on / slow to fast	0–24 / 25–255
7	Pattern A — off / select	0–4 / 5–255
8	Pattern B — off / select	0–4 / 5–255
9	Foreground Color — off / select	0–4 / 5–255
10	Background Color — off / select	0–4 / 5–255
11	Image Orientation — normal / reverse	0–127 / 128–255
12	Built-in Effect — off / select	0–4 / 5–255
13	Effect Speed — slow to fast	0–255
14	RGB Red — intensity	0–255
15	RGB Green — intensity	0–255
16	RGB Blue — intensity	0–255
17	White Strobe Dimmer — 0–100%	0–255
18	White Strobe Speed — constant on / slow to fast	0–24 / 25–255
19	White Auto Effect — off / automatic effect*	0–5 / 5–255
20	White Effect Speed — slow to fast	0–255

*The source table overlaps at DMX value 5 on channel 19. The documented ranges are retained pending confirmation.

41 CH — 8-Segment RGB Control

Channels 1–17 manage movement, dimming, strobe and effects. Channels 18–41 control eight RGB segments.

CH	Function / Operation	DMX Range
1	Tilt — vertical movement	0–255
2	Tilt Fine — 16-bit adjustment	0–255
3	Tilt Speed — fast to slow	0–255
4	Reset — no function / full reset	0–126 / 127–128
5	Master Dimmer — 0–100%	0–255
6	RGB Strobe / Flicker — constant on / slow to fast	0–24 / 25–255
7	Pattern A — off / select	0–4 / 5–255
8	Pattern B — off / select	0–4 / 5–255
9	Foreground Color — off / select	0–4 / 5–255
10	Background Color — off / select	0–4 / 5–255
11	Image Orientation — normal / reverse	0–127 / 128–255
12	Built-in Effect — off / select	0–4 / 5–255
13	Effect Speed — slow to fast	0–255
14	White Strobe Dimmer — 0–100%	0–255
15	White Strobe Speed — constant on / slow to fast	0–24 / 25–255
16	White Auto Effect — off / automatic effect*	0–5 / 5–255
17	White Effect Speed — slow to fast	0–255

RGB Segment Map

Segment	Red	Green	Blue
1	CH18	CH26	CH34
2	CH19	CH27	CH35
3	CH20	CH28	CH36
4	CH21	CH29	CH37
5	CH22	CH30	CH38
6	CH23	CH31	CH39
7	CH24	CH32	CH40
8	CH25	CH33	CH41

*The source table overlaps at DMX value 5 on channel 16. The documented ranges are retained pending confirmation.

312 CH — Full Pixel Mapping

This personality allocates four channels to movement and reset, 20 channels to white segments, and 288 channels to 96 RGB segments.

CH1: Tilt
CH2: Tilt Fine
CH3: Tilt Speed
CH4: Reset
CH5–CH24: 20 white segments, 0–255 each
CH25–CH312: 96 RGB segments

Pixel Channel Mapping

Component	Channel Range	Channel Formula
White 1–20	CH5–CH24	Channel = 4 + segment number
Red 1–96	CH25–CH120	Channel = 24 + pixel number
Green 1–96	CH121–CH216	Channel = 120 + pixel number
Blue 1–96	CH217–CH312	Channel = 216 + pixel number

Reference Pixels

Pixel	Red	Green	Blue
1	CH25	CH121	CH217
2	CH26	CH122	CH218
48	CH72	CH168	CH264
96	CH120	CH216	CH312

Package Contents

1 × REDJET STROBE 1212LS fixture
1 × power cable
1 × user manual

Fixture dimensions: approximately 516 × 215 × 229 mm. Net weight, boxed weight and shipping carton dimensions are not yet physically verified.

Applications

Concerts, touring productions, rental inventories, clubs, live venues, TV and broadcast installations, and pixel-mapped lighting shows.
