Product Positioning

High-intensity beam, sharp aerial effects, prism layering, and precision optics for professional stage,
touring, and club applications.

Technical Specifications

Electrical

Light Source

Control

Mechanical

Optical & Performance Features

Display

• 650,000-color TFT LCD touch screen
• Reversible interface (180° rotation)

Pan / Tilt

• Pan (X-axis): 540°
• Tilt (Y-axis): 270°
• Automatic reset, correction, and precise positioning
• Fine adjustment via software calibration

Dimming

• 0–100% linear dimming

Strobe

• Single-chip strobe
• Speed: 0.5–9 Hz
• Full linear dimming with variable strobe speed

Effects System

Color Wheel

• 14 colors + open (Sharp air beam effects)

Gobo Wheel

• 5 glass gobos
• 9 fixed gobos
• Open (Rapid beam shape changes)

Prism System

• Dual prism discs
• Honeycomb prism + double prism effect
• Bi-directional rotation
• Adjustable speed

Frost (Atomization)

• Soft light diffusion for smooth pattern effects

Rainbow Effect

• 7-color flowing rainbow

Focus System

• Multi-group optical lens combination
• High-definition pattern projection, superior to standard beam fixtures

Beam Angle

• Parallel beam: 0° – 3.8°

Protection & Intelligence

• Intelligent overheating protection
• Smart lamp on/off control (extends lamp life)
