PIXEL 1812 RGBW is a professional RGBW pixel LED bar featuring 18 × 12W 4-in-1 LEDs with individual pixel control.
Designed for stage, rental, touring, and architectural applications, it delivers dynamic pixel-mapping effects,
smooth 0–100% electronic dimming, and versatile operation via DMX512, Auto Run, and Sound Active modes.
PIXEL 1812 RGBW
Pricing available upon request.
Please contact our sales team for technical consultation and quotation.
PIXEL 1812 RGBW
Pixel LED Bar Light
Overview
PIXEL 1812 RGBW is a professional RGBW pixel LED bar designed for stage, rental,
touring, and architectural lighting applications. Featuring individual pixel control,
matrix effects, and rich built-in programs, it delivers dynamic chases, strobes,
and pixel-mapping visuals under DMX control.
Technical Specifications
Electrical
| Power Supply | AC 100–230 V, 50/60 Hz |
|---|---|
| Power Draw | 200 W |
| Multi-Voltage Operation | Yes |
Light Source
| LED Source | 18 × 12 W RGBW (4-in-1) LED chips |
|---|---|
| LED Beam Angle | 45° |
| LED Lifetime | 60,000 – 100,000 hours |
Control
| Control Signal | DMX512 |
|---|---|
| DMX Channel Modes | 9 CH / 72 CH / 76 CH |
| Control Modes | DMX512, Master/Slave, Auto Run, Sound Active |
Mechanical
| Housing | Aluminum |
|---|---|
| DMX Connection | 3-Pin XLR In / Out |
| Power Connection | PowerCON In / Out |
Optical & Performance Features
Dimming
- Electronic dimming: 0–100%
Strobe / Pulse
- Electronic strobe and pulse effects
- Random strobe from slow to fast
Pixel Control
- Individual LED pixel dot control
- Matrix and pixel-mapping effects
Operation & Programs
- Automatic modes via function buttons
- DMX512 / Auto Run / Sound Active / Strobe modes
- Stand-alone operation
- Master/Slave operation with advanced built-in programs
User Interface
- LED display operation menu
