STROBE 1212LS

REDJET STROBE 1212LS 400 W Motorized RGB Pixel Strobe

(2 customer reviews)
$2,000.00

The REDJET STROBE 1212LS is a 400 W motorized RGB pixel strobe with 96 RGB segments and 20 independent white strobe zones. Motorized tilt, 1–30 Hz flash control and four DMX personalities make it a flexible choice for concerts, touring productions and professional stages.

Rated power
400 W
Control
DMX512, RDM, Auto, Sound, Master/Slave
Movement
Motorized
Strobe frequency
1–30 Hz

Description

REDJET / PROFESSIONAL STAGE LIGHTING

STROBE 1212LS

Motorized RGB Pixel Strobe

Creative RGB pixels, brilliant white strobe zones and precise motorized tilt — engineered for impactful, flexible stage effects.

400 W

Rated power

96 RGB

Pixel segments

20 White

Strobe zones

4 Modes

DMX personalities

Product Overview

The REDJET STROBE 1212LS combines 864 RGB LEDs, 180 white LEDs and motorized tilt in one professional lighting fixture. Designed for rental, touring, live events and installed stages, it provides built-in effects for fast setup and detailed pixel control for more advanced programming.

Key Features

Pixel Colour

96 independent RGB segments powered by 864 × 0.3 W RGB LEDs for dynamic, detailed colour patterns.

White Strobe

20 independent white zones with 180 × 3 W LEDs and adjustable 1–30 Hz strobe effects.

Motorized Tilt

Fine positioning and movement-speed adjustment support animated sequences and accurate fixture control.

DMX Flexibility

Work with 6, 20, 41 or 312 DMX channels; DMX512, RDM, Auto, Sound and Master/Slave control modes.

Technical Specifications

Explore the main parameters below. Detailed channel assignments remain available without crowding the product page.

Lighting & Performance
Product TypeMotorized RGB Pixel Strobe
Rated Power400 W
RGB Source864 × 0.3 W RGB LEDs
White Source180 × 3 W white LEDs
Pixel & Strobe Zones96 RGB + 20 independent white
Strobe Frequency1–30 Hz
Dimming32-bit linear, 0–100%
Control, Movement & Electrical
DMX Personalities6 / 20 / 41 / 312 CH
Control ModesDMX512, RDM, Auto, Sound, Master/Slave
MovementMotorized tilt with fine and speed control
Power SupplyAC 100–240 V, 50/60 Hz
Operating Temperature−30 °C to +50 °C
Housing ProtectionIP20
Fixture DimensionsApprox. 516 × 215 × 229 mm
DMX Control — Which Mode Should I Choose?
  • 6 CH: Basic tilt, reset, white output and RGB intensity.
  • 20 CH: Movement, dimming, strobe and built-in effects.
  • 41 CH: Expanded control of eight RGB segments.
  • 312 CH: Independent control of 96 RGB segments and 20 white zones.
Advanced DMX Channel Maps — 6 / 20 / 41 / 312 CH

The detailed assignments below are retained for lighting-console programming. Select the personality that matches your controller configuration.

6 CH — Basic Control

Compact control of tilt, reset, white output and direct RGB intensity.

CHFunction / OperationDMX Range
1Tilt — motorized tilt0–255
2Reset — no function / full reset0–126 / 127–128
3White Strobe Dimmer — 0–100%0–255
4Red — intensity0–255
5Green — intensity0–255
6Blue — intensity0–255
20 CH — Recommended

General-purpose control with movement, RGB intensity, white strobe and built-in effects.

CHFunction / OperationDMX Range
1Tilt — vertical movement0–255
2Tilt Fine — 16-bit adjustment0–255
3Tilt Speed — fast to slow0–255
4Reset — no function / full reset0–126 / 127–128
5Master Dimmer — 0–100% intensity0–255
6RGB Strobe / Flicker — constant on / slow to fast0–24 / 25–255
7Pattern A — off / select0–4 / 5–255
8Pattern B — off / select0–4 / 5–255
9Foreground Color — off / select0–4 / 5–255
10Background Color — off / select0–4 / 5–255
11Image Orientation — normal / reverse0–127 / 128–255
12Built-in Effect — off / select0–4 / 5–255
13Effect Speed — slow to fast0–255
14RGB Red — intensity0–255
15RGB Green — intensity0–255
16RGB Blue — intensity0–255
17White Strobe Dimmer — 0–100%0–255
18White Strobe Speed — constant on / slow to fast0–24 / 25–255
19White Auto Effect — off / automatic effect*0–5 / 5–255
20White Effect Speed — slow to fast0–255

*The source table overlaps at DMX value 5 on channel 19. The documented ranges are retained pending confirmation.

41 CH — 8-Segment RGB Control

Channels 1–17 manage movement, dimming, strobe and effects. Channels 18–41 control eight RGB segments.

CHFunction / OperationDMX Range
1Tilt — vertical movement0–255
2Tilt Fine — 16-bit adjustment0–255
3Tilt Speed — fast to slow0–255
4Reset — no function / full reset0–126 / 127–128
5Master Dimmer — 0–100%0–255
6RGB Strobe / Flicker — constant on / slow to fast0–24 / 25–255
7Pattern A — off / select0–4 / 5–255
8Pattern B — off / select0–4 / 5–255
9Foreground Color — off / select0–4 / 5–255
10Background Color — off / select0–4 / 5–255
11Image Orientation — normal / reverse0–127 / 128–255
12Built-in Effect — off / select0–4 / 5–255
13Effect Speed — slow to fast0–255
14White Strobe Dimmer — 0–100%0–255
15White Strobe Speed — constant on / slow to fast0–24 / 25–255
16White Auto Effect — off / automatic effect*0–5 / 5–255
17White Effect Speed — slow to fast0–255

RGB Segment Map

SegmentRedGreenBlue
1CH18CH26CH34
2CH19CH27CH35
3CH20CH28CH36
4CH21CH29CH37
5CH22CH30CH38
6CH23CH31CH39
7CH24CH32CH40
8CH25CH33CH41

*The source table overlaps at DMX value 5 on channel 16. The documented ranges are retained pending confirmation.

312 CH — Full Pixel Mapping

This personality allocates four channels to movement and reset, 20 channels to white segments, and 288 channels to 96 RGB segments.

  • CH1: Tilt
  • CH2: Tilt Fine
  • CH3: Tilt Speed
  • CH4: Reset
  • CH5–CH24: 20 white segments, 0–255 each
  • CH25–CH312: 96 RGB segments

Pixel Channel Mapping

ComponentChannel RangeChannel Formula
White 1–20CH5–CH24Channel = 4 + segment number
Red 1–96CH25–CH120Channel = 24 + pixel number
Green 1–96CH121–CH216Channel = 120 + pixel number
Blue 1–96CH217–CH312Channel = 216 + pixel number

Reference Pixels

PixelRedGreenBlue
1CH25CH121CH217
2CH26CH122CH218
48CH72CH168CH264
96CH120CH216CH312

Applications

For concerts, touring shows, rental systems, event production, live venues and broadcast stages requiring colour pixels, powerful white strobe effects or motorized movement.

What’s Included

  • 1 × REDJET STROBE 1212LS fixture

Compatibility & Notes

The 6 / 20 / 41 / 312 CH options are DMX control modes of the same fixture, not separate purchase variants. Use the matching console personality and verify connection and installation requirements before operation. Carton measurements and packed weight are not confirmed.

Watch the STROBE 1212LS

Watch the product video on YouTube

Additional information

Product Type

Moving Head

Movement

Motorized

Product resources are listed immediately below.
