Description
EAGLE LIGHT CM001I Video Lighting Server
The EAGLE LIGHT CM001I is a video lighting server designed for synchronized control of stage lighting, sound, video, effects and compatible electrical equipment. Its manufacturer catalog describes integrated show playback and control, allowing incoming Art-Net or DMX512 lighting data to be recorded as effect content and combined with the documented audio, video and external control interfaces.
Key Features & Benefits
- Coordinated show control: Supports synchronized operation of lighting effects, audio, video, power supply equipment and compatible intelligent electrical appliances.
- Art-Net and DMX512 recording: Records lighting control data received from external Art-Net or DMX512 as show-effect content.
- Four-channel DMX512 input and output: The manufacturer specifies four DMX512 inputs and four DMX512 outputs, alongside Art-Net input/output.
- Central-control integration: RS485 and TCP/UDP central-control input/output connections are specified.
- Audio and video outputs: Provides 3.5 mm audio output, 6.35 mm/XLR balanced audio output and HDMI/VGA video outputs for a background display.
- Touch-screen and remote operation: Features a 7-inch touch screen and phone/tablet Wi-Fi operation when connected to a router.
- Flexible effect triggering: Effect output can be controlled from the front panel or triggered by an external sensor; other listed modes include direct console-signal output and console-recall control.
- Rack integration: Standard 19-inch 3U installation size; manufacturer lists a dedicated cabinet keyboard as an available option.
Professional Show Control Applications
The CM001I is intended for professional integrated show-control racks where Art-Net/DMX512 lighting data, audiovisual outputs and networked control must work together. Choose connected equipment and wiring according to the supported interfaces; the catalog does not provide an exhaustive list of interoperable devices or signal mapping limits.
Verified Technical Specifications
| Brand | EAGLE LIGHT |
|---|---|
| Catalog model | CM001I |
| Product designation | Video Lighting Server |
| External effect-data recording | Art-Net or DMX512 lighting input |
| Art-Net | Input / output |
| DMX512 input | 4 channels |
| DMX512 output | 4 channels |
| RS485 central control | Input / output |
| TCP/UDP central control | Input / output |
| Audio outputs | 3.5 mm; 6.35 mm/XLR balanced |
| Video outputs | HDMI and VGA |
| Screen | 7-inch touch screen |
| Wi-Fi operation | Phone / tablet via connected router |
| Effect trigger | Panel or external sensor |
| Listed output modes | One-key server output; direct console signal; effect output through console recall |
| Mounting | Standard 19-inch, 3U |
| Input voltage | AC 90–240 V |
Catalog Model Identification Notice
Model identification notice: The catalog heading lists CM001I, the photographed front panel is marked CM001, and the system diagram is marked CM001H. The manufacturer catalog does not establish whether these are the same hardware revision. The product is listed under the catalog heading CM001I; confirm the delivered hardware label with the supplier before ordering.
Source: EAGLE LIGHT manufacturer catalog, PDF page 27. No specifications, certifications or model equivalences beyond the supplied source are assumed.
