EAGLE LIGHT CB0401-S 4-Channel RDM/DMX512 Signal Demultiplexer
The EAGLE LIGHT CB0401-S is the signal-distribution module in the manufacturer's four-channel RDM/DMX512 multiplexer system. It receives the combined cable link from the matching CB0401-M merger and restores four independent RDM/DMX512 output signal paths, as illustrated in the catalog.
Key Features & Benefits
- Four independent signal outputs: Restores the merged network-cable link to four separate RDM/DMX512 signal outputs.
- Companion of CB0401-M: Works as the destination-side unit in the manufacturer-illustrated CB0401-M/CB0401-S combination.
- One transmission link: The catalog's diagram shows one network cable between the signal-merging and signal-restoration modules.
- Product-specific connector view: The manufacturer separately labels this four-connector unit 'Splitter: CB0401-S'.
- Practical mounting options: The family diagrams depict pipe-clamp installation and clamp mounting for the units.
Professional DMX & RDM Applications
Use the CB0401-S at the far end of a CB0401 multiplexer cabling link to restore the four RDM/DMX512 signal paths for compatible lighting fixtures. The manufacturer's network-cable wording does not establish Ethernet/IP, Art-Net, PoE, transmission distance or power requirements.
Verified Technical Specifications
| Brand | EAGLE LIGHT |
|---|---|
| Catalog model | CB0401-S |
| Product family | 4-Channel RDM/DMX512 Multiplexer |
| Product role | Signal splitter / demultiplexer / reception-end module |
| RDM/DMX512 signal outputs | 4 independent channels |
| Transport concept | Restores four channels from a shared network-cable link |
| Paired merger module | CB0401-M (listed separately) |
Manufacturer Model Identification
Model identification: The family is headed CB0401-(S/M)P, while the individual splitter is labeled CB0401-S in the product entry and diagram. The catalog does not verify an additional 'P' suffix in this variant's purchase code. This listing preserves CB0401-S as the documented individual module identifier; confirm the ordering code with the supplier.
Technical claims are limited to the user-supplied EAGLE LIGHT manufacturer catalog, PDF page 9 (printed page 5). No undocumented electrical ratings, performance data or certifications have been estimated.
